1300x1300mm 3-Runner Flat Plastic Pallet XYJ-1313-CP

The XYJ-1313-CP is a heavy-duty 3-runner flat plastic pallet with a modular deck and leg design. Reinforced with up to 12 internal steel tubes, this 1300×1300×170mm HDPE pallet delivers high static load capacity for racking and bulk storage. Featuring 4-way forklift entry and a smooth, non-slip surface, it is ideal for chemical drums, bags, and automated warehouse systems.

Material

HDPE/PP

Plastic Pallet Size

1300x1300x170mm

Base Support Type

3 Runners

Deck Surface

Solid Flat Deck

Product Gallery

Product Specification

Model:​ XYJ-1313-CP​
Dimensions:​ 1300 mm (L) × 1300 mm (W) × 170 mm (H)
Structure:​ Modular Assembled (Detachable Top Panel & 3-Runner Legs)
Deck Type: ​ Closed/Smooth Flat Top (Hygienic)
Base Type: 3-Runner
Steel reinforced: Max 12pcs steel bars
Material Virgin HDPE (High-Density Polyethylene)/ PP
Static Load: ​ 6000 kg (Typical)
Dynamic Load:​ 1500~2000 kg (w/ steel)
Racking Load: ​ 1000–1500 kg(w/ steel)
Entry: ​ 4-way entry (Forklift & Hand Pallet Truck compatible)
Feature: ​ Non-porous, Easy-to-clean, Repairable

The XYJ-1313-CP 3-Runner Flat Plastic Pallet is engineered for high-density storage and demanding logistics environments. Measuring 1300×1300×150mm, this pallet features a unique modular assembly design​ where the flat deck and three runners (the “Sichuan” or river-like base) are manufactured separately and locked together. This construction allows for the integration of up to 12 internal galvanized steel tubes, significantly boosting its rigidity and load-bearing capacity for selective racking systems. Made from 100% virgin HDPE, the XYJ-1313-CP resists moisture, insects, and chemicals, making it a superior alternative to wooden pallets in food processing, pharmaceuticals, and chemical storage. The smooth, flat top deck protects bagged goods from punctures and ensures easy cleaning, while the 3-runner bottom provides stable support in racking and prevents sagging. With 4-way entry for forklifts and compatibility with most pallet jacks, this pallet optimizes workflow in warehouses and distribution centers.

Product Feature

  • Modular Assembly Advantage:​ Unlike one-piece molded pallets, the XYJ-1313-CP’s deck and runners are separate. If a runner is damaged, you replace only that part—not the entire pallet—drastically reducing long-term costs.
  • 12-Steel Tube Reinforcement:​ Internal steel tubing transforms this plastic pallet into a racking-safe powerhouse, preventing beam deflection and supporting heavy loads in selective racks..
  • Hygienic Flat Deck:​ The smooth, seamless top surface prevents bacterial growth and protects packaged goods (bags, sacks, cartons) from bottom-board snagging or contamination.
  •  Logistics Ready:​ Durable enough for multi-trip use in closed-loop supply chains.
  • 4-Way Versatility:​ Accessible from all four sides by forklifts and pallet jacks, ensuring fast loading/unloading in tight warehouse aisles.

FAQs

Simply provide the following details, and our sales team will propose the most suitable models for you:

  • Pallet Size: Length × Width × Height

  • Pallet Usage: Warehouse racking use, warehouse stacking storage, or one-way shipping use?

  • Pallet Load Capacity: Dynamic load, static load, and racking load accordingly.

Yes! Color customization is available based on your requirements:

General Lead Time: 15–20 days upon receipt of advance payment.

  • Delivery Guarantee: Once a formal order is placed, we will issue a production plan to strictly guarantee on-time delivery.

  • Standard Method: T/T is commonly used.

  • Alternative Options: We also accept L/C, PayPal, Western Union, or other methods according to the specific situation.

  • Yes, we offer the following value-added services:

    • Logo Printing: Brand your pallets with your company logo.

    • Customized Colors: Match the pallets to your brand identity.

    • Free Detention & Demurrage (Det+Dem): Enjoy free demurrage and detention time at the destination port.

    • Warranty: We provide a 3-year warranty for our products.

Multicolor
Food Safety
Anti-slip
100% Recyclable
Client Specific Marks
